Yattox 5S 5200mAh 60C 100%LCO Lipo Battery
Yattox 5S 5200mAh 60C 100%LCO Lipo Battery is backordered and will ship as soon as it is back in stock.
لم نتمكن من تحميل توفر الاستلام
Specifications：
-
Capacity： 5200mAh
-
Voltage： 18.5V / 5-Cell / 5S1P
-
Discharge Rate： 60C Continual / 120C Burst
-
Charge Rate： 2C Max
-
Size（1-5mm difference）： 137 × 45× 54 mm
-
Approx Weight（±5g）： 610g
-
Output Connector： EC5/XT90
-
Balance Connector： JST-XH
-
Wire（AWG）： 10#
- cathode material：100% LCO
Yattox 5S 5200mAh 60C 100%LCO Lipo Battery
خدمة التخصيص
نظرًا لأننا نتحكم في كل خطوة من خطوات الإنتاج - من مطابقة الخلايا إلى تجميع العبوة النهائية - يمكننا تخصيص الجهد ومعدل التفريغ وأنواع الموصلات بمرونة. عند تقديم الطلب، يمكنك تحديد نوع القابس ومعدل C.
High-C production workshop
-
Cell Formation & Aging System
Through tightly controlled formation and aging processes under stable temperature conditions, we stabilize the SEI layer, screen early failures, and ensure consistent internal resistance across cells. -
Ultra-Low Humidity Dry Room
Critical processes are carried out in an ultra-dry environment (≤1% RH, dew point ≤ −40°C),ensuring low internal resistance, consistency, and stable high-rate performance.
-
Electrode Consistency & Calendering Control
High-rate performance depends on consistency.
By tightly controlling coating thickness and calendering density, we ensure uniform current paths and low impedance across cells, enabling stable and repeatable high C-rate performance.
